Technical Specification | ||
Expansion Slots | AMD Ryzen series CPUs (Summit Ridge and Pinnacle Ridge) - 1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode)* AMD Ryzen series CPUs (Raven Ridge) - 1 x PCI Express 3.0 x16 Slot (PCIE2: x8 mode)* AMD Athlon series CPUs - 1 x PCI Express 3.0 x16 Slot (PCIE2: x4 | |
Basic Information | ||
Supported CPU | AMD AM4 Socket - Digi Power design - Supports CPU up to 105W | |
Chipset | AMD Promontory B450 | |
BIOS | 128Mb AMI UEFI Legal BIOS with GUI support - SMBIOS 2.3 support | |
Form Factor | Micro ATX Form Factor: 9.1-in x 8.1-in, 23.1 cm x 20.6 cm | |
Memory Specifications | ||
Memory | Dual Channel DDR4 Memory Technology, 2 x DDR4 DIMM Slots - 15μ Gold Contact in DIMM Slots, For Ryzen Series CPUs (Raven Ridge), ECC is only supported with PRO CPUs. | |
Graphics Specifications | ||
Graphics | Max Shared memory supports up to 16GB - The Max shared memory 16GB requires 32GB system memory installed. | |
Warranty Information | ||
Manufacturing Warranty | 03 Years warranty |
