General | ||
Model | Asus ROG STRIX B460-F GAMING | |
Chipset | Intel B460 | |
Form Factor | ATX | |
Additional Info | ||
BIOS Type | 128 Mb Flash | |
BIOS Model | AMI UEFI BIOS | |
Thunderbolt | Yes | |
RGB Support | Yes | |
RGB Sync | Aura Sync | |
RGB Connector | 2 x Aura RGB Strip Headers | |
Memory Specifications | ||
Type | DDR4 | |
MHz | 2933/ 2800/ 2666/ 2400/ 2133 MHz | |
Channel | Dual | |
Slot | 4 | |
Max | 128GB | |
Optane Memory Support | Yes | |
Graphics Specifications | ||
Graphics | Integrated Graphics | |
Multi-GPU Support | 2-Way AMD CrossFireX Technology | |
PCI Express Slot | 1 PCIe 3.0 x16, 3 PCIe 3.0 x1 | |
CrossFire Support | Yes | |
Sli Support | No | |
Warranty Information | ||
Manufacturing Warranty | 03 Years | |
Compatibility | ||
Sockets Supported | LGA1200 | |
Supported CPU | 10th Generation Intel Core i9 / i7 / i5 / i3 / Pentium Gold / Celeron Processors | |
Generation | 10th | |
Supported Operating System | Windows 10 | |
Storage | ||
Storage Interface | 6.0Gb/s | |
M.2/SSD Expansion Slot | 2 | |
SATA Port | 6 x SATA | |
Raid Support | 0, 1, 5, 10 | |
Network & Connectivity | ||
LAN Chipset | Intel I219-V | |
LAN Speed (Mbps) | 10/100/1000 | |
Ports | ||
USB Port | 1 x USB 3.2 Gen 2x2 Type-C, 7 x USB 3.2 Gen 1, 3 x USB 2.0 | |
HDMI Port | 1 | |
Audio & Video | ||
Audio Chipset | ROG SupremeFX | |
Audio Channel | 7.1 |
The robust power design and comprehensive cooling features of Strix B460-F Gaming ensure great all-round performance, and an intuitive dashboard gives you full networking control so you can harness the full potential of your build.
Teamed power stages combine high-side and low-side MOSFETs and drivers into a single package, delivering the power and efficiency that the latest Intel processors demand.
The ProCool socket is built to exacting specifications to ensure flush contact with the PSU power lines, enabling lower impedance and better heat dissipation.
Superior chokes and durable capacitors are engineered to resist extreme temperatures and provide up to 110% better performance than the industry standard.
The proprietary ROG GameFirst VI utility is designed to help all users — beginners, experts, and everyone in between — optimize network settings to ensure smooth online gameplay. New to this generation, GameFirst VI features AI-enhanced identification and boost technology to ensure faster and smarter network optimization.
Identification
GameFirst VI analyzes your usage patterns and the digital signatures of your applications and compares them to a database of over 200,000 apps. The database is regularly updated to ensure that apps are recognized.
Boost
GameFirst VI intelligently switches application priority and adjusts bandwidth accordingly, depending on the situation. When gaming, it accelerates and prioritizes game packets to give you supersmooth online gameplay — even when you're streaming high-quality video to your audience or transferring large files.
Visualization
An intuitive graph gives you an overview of the network in real-time. Simply click on the tab to view current bandwidth usage of each application, geolocation status of each network connection, and an analysis of each WiFi channel.
Brand - Asus, Model - Asus ROG STRIX B460-F GAMING, CPU Sockets - LGA1200, Chipset - Intel B460, Supported CPU - Intel Core i9/ i7/ i5/ i3/ Pentium Gold/ Celeron Processors, Generation - 10th, Memory Type - DDR4, Memory MHz - 2933/ 2800/ 2666/ 2400/ 2133 MHz, Memory Channel - Dual Channel, Memory Slot - 4, Memory Max. - 128GB, Optane Memory Support - Yes, Graphic - Integrated Graphics, Multi-GPU Support - 2-Way AMD CrossFireX Technology, PCI Express Slot - 1 PCIe 3.0 x16, 3 PCIe 3.0 x1, Storage Interface - 6Gb/s, M.2 Slot - 2 x M.2 (1 x M.2_1 socket 3 M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode) (1 x M.2_2 socket 3 M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)), LAN Chipset - Intel I219-V, LAN Speed (Mbps) - 10/100/1000, Audio Chipset - ROG SupremeFX, Audio Channel - 7.1 - Channel, Wi-Fi - No, Bluetooth - No, USB Port - 1 x USB 3.2 Gen 2x2 Type-C, 7 x USB 3.2 Gen 1, 3 x USB 2.0, VGA Port - No, DVI Port - No, HDMI Port - 1, DisplayPort (DP) - No, IDE Port - No, SATA Port - 6 x SATA, BIOS Type - 128 Mb Flash, BIOS Model - AMI UEFI BIOS, FireWire - No, CrossFire Support - Yes, Sli Support - No, RaidSupport - 0, 1, 5, 10, Thunderbolt - 1 x Thunderbolt, TPM Port - No, COM Port - No, RGB Support - Yes, RGB Sync - Aura Sync, RGB Connector - 2 x Aura RGB Strip Headers, Form Factor - ATX, Supported Operating System - Windows 10, Special Features - ROG Strix B460-F Gaming motherboard features solid power delivery and effective cooling designed to handle the latest 10th Generation Intel Core processors. With its arresting futuristic aesthetic and intuitive ROG software, ROG Strix B460-F Gaming gives you a head start on your dream gaming build. Extreme Engine Digi+ - 5K Black Metallic Capacitors, ASUS Q-Design - ASUS Q-DIMM - ASUS Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) - ASUS Q-Slot, ASUS Thermal Solution - Aluminum M.2 heatsink, ASUS EZ DIY - BIOS FlashBack button - BIOS FlashBack LED - Procool - Pre-mounted I/O shield - SafeSlot, AURA Sync - Standard RGB header(s) - Addressable Gen 2 RGB header(s), Rear audio USB Type-C connector, Others - 1 x M.2 with E key for Wi-Fi module, 6 x SATA 6Gb/s connector(s), 1 x S/PDIF out header(s), 1 x Thunderbolt header(s), 1 x 24-pin EATX Power connector(s), 1 x 8-pin ATX 12V Power connector(s), 1 x Clear CMOS jumper(s), 1 x System panel connector, 1 x CPU Fan connector(s), 1 x CPU OPT Fan connector(s), 3 x Chassis Fan connector(s), 1 x AIO_PUMP connector, 1 x AAFP connector, 2 x Addressable Gen 2 header(s), 1 x Intel I219-V 1Gb Ethernet, 1 x DisplayPort, 1 x HDMI, 1 x USB 3.2 Gen 2x2 port(s) (1 x USB Type-C), 6 x USB 3.2 Gen 1, 1 x USB 2.0 (1 for audio USB Type-C), 5 x Audio jack(s), 1 x USB BIOS FlashBack Button(s), Warranty - 3 Year, Country of Origin - Taiwan, Made in/ Assemble - China
