Technical Specification | ||
Expansion Slots | Intel® H310 Chipset 1 x PCIe 3.0/2.0 x16 (x16 mode) 2 x PCIe 2.0 x1, 1 x M.2 Socket 3, with M Key, type 2242/2260/2280 storage devices support(both PCIE 2.0 x4 & SATA mode) | |
Basic Information | ||
Supported CPU | Intel® Socket 1151 for 8th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors Supports Intel® 14 nm CPU Supports Intel® Turbo Boost Technology 2.0 | |
Chipset | Intel® H310 | |
BIOS | 128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information, F4 AUR | |
Form Factor | Micro ATX Form Factor 8.9 inch x 8.2 inch ( 22.6 cm x 20.8 cm ) | |
Physical Description | ||
HDMI | 1 x HDMI | |
USB (s) | Intel® H310 Chipset : 4 x USB 3.1 Gen 1 up to 5Gbps port(s) (2 at back panel, blue, Type-A, 2 at mid-board) Intel® H310 Chipset : 6 x USB 2.0/1.1 port(s) (4 at back panel, black, Type-A, 2 at mid-board) | |
LAN Port (s) | Intel® I219V, 1 x Gigabit LAN Controller(s) TUF LANGuard | |
Audio | Realtek® ALC887 7.1-Channel High Definition Audio CODEC *2 Audio Feature : - Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference - Dedicated audio PCB layers: Separate layers for left and right channe | |
Internal I/O Ports | 1 x RGB Header(s) 1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin) 1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s) 1 x M.2 Socket 3 1 x COM port(s) connector(s) 4 x SATA 6Gb/s connector(s) | |
Memory Specifications | ||
Type | 2 x DIMM | |
Slots | DDR4 2666/2400/2133 MHz Non-ECC, Un-buffered Memory | |
Supported Memory | DDR4 2666MHz and higher memory modules will run at max. 2666MHz on Intel® 8th Gen. 6-core or higher processors. | |
Maximum Mamory | 32GB | |
Graphics Specifications | ||
Graphics | Multi-VGA output support : HDMI/DVI-D ports - Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz - Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz | |
Max Shared Memory | 1024 MB | |
Warranty Information | ||
Manufacturing Warranty | 03 years |
